MINI-PS-100-240AC/2X15DC/1
6
L (+)
Block diagram
7
NC
NC
N (-)
OV
OV
Safety notes
DANGER OF EXPLOSION!
Only remove equipment when it is disconnected and not in the potentially explosive area.
DANGER
Components with dangerously high voltage and high stored energy are located in the device!
Never carry out work on live parts!
Depending on the ambient temperature and the load, the housing can become very hot!
Cover termination area after installation in order to avoid accidental contact with live parts (e. g., installation in
control cabinet).
CAUTION:
Before startup please ensure:
The mains connection has been carried out by a competent person and protection against electric shock is
guaranteed!
The device can be disconnected outside the power supply unit in accordance with the regulations as in EN
60950 (e.g. through primary side line protection)!
All feed lines are sufficiently protected and dimensioned!
All output lines are dimensioned according to the maximum output current of the device or separately
protected!
Sufficient convection must be guaranteed.
ATTENTION: Danger if used improperly
The power supply units are built-in devices. The device may only be installed and put into operation by qualified
personnel. The corresponding national regulations must be observed.
Note: Electrical damage
Plug connectors may only be connected/disconnected when under no load.
100299_en_04
PHOENIX CONTACT
7
